Elixir M2Y2G64CB8HA9NDG Ficha de datos Pagina 12
- Pagina / 24
- Tabla de contenidos
- MARCADORES
Valorado. / 5. Basado en revisión del cliente
M2Y1G64CB88A9N / M2Y2G64CB8HA9N
1GB: 128M x 64 / 2GB: 256M x 64
Unbuffered DDR3 SDRAM DIMM
REV 1.0 12
11/2008
© NANYA TECHNOLOGY CORP.
NANYA TECHNOLOGY CORP. reserves the right to change Products and Specifications without notice.
Operating, Standby, and Refresh Currents
T
CASE
= 0 °C ~ 85 °C; V
DDQ
= V
DD
= 1.5V ± 0.075V (1GB, 1 Rank, base on 128Mx8 DDR3 SDRAMs)
Symbol
Parameter/Condition
DDR3-1066
DDR3-1333
DDR3-1600
Unit
I DD0
Operating Current: one bank activate/Precharge
968
1056
1056
mA
I DD1
Operating Current: one bank activate/Read/Precharge
1100
1188
1276
mA
I DD2P(0)
Precharge Power-Down Current Fast Exit-MR0 bit A12=0
141
141
141
mA
I DD2P(1)
Precharge Power Down Current Slow Exit-MR0 bit A12=1
264
264
264
mA
I DD2N
Precharge Standby Current
572
616
660
mA
I DD2Q
Precharge Quiet Standby current
484
528
572
mA
I DD3P
Active Power-Down Current Always Fast Exit
352
396
440
mA
I DD3N
Active Standby Current
572
616
660
mA
I DD4W
Operating Current: Burst Write
1408
1760
2024
mA
I DD4R
Operating Current: Burst Read
1408
1760
2200
mA
I DD5B
Burst Refresh Current
2200
2376
2552
mA
I DD6
Self-Refresh Current Normal Temperature Range (0-85C)
123
123
123
mA
I DD7
All Bank Interleave Read Current
2640
3168
3432
mA
Note: Module IDD was calculated from component IDD. It may differ from the actual measurement.
Operating, Standby, and Refresh Currents
T
CASE
= 0 °C ~ 85 °C; V
DDQ
= V
DD
= 1.5V ± 0.075V (2GB, 2 Ranks, base on 128Mx8 DDR3 SDRAMs)
Symbol
Parameter/Condition
DDR3-1066
DDR3-1333
DDR3-1600
Unit
I DD0
Operating Current: one bank activate/Precharge
1540
1672
1716
mA
I DD1
Operating Current: one bank activate/Read/Precharge
1672
1804
1936
mA
I DD2P(0)
Precharge Power-Down Current Fast Exit-MR0 bit A12=0
282
282
282
mA
I DD2P(1)
Precharge Power Down Current Slow Exit-MR0 bit A12=1
528
528
528
mA
I DD2N
Precharge Standby Current
1144
1232
1320
mA
I DD2Q
Precharge Quiet Standby current
968
1056
1144
mA
I DD3P
Active Power-Down Current Always Fast Exit
704
792
880
mA
I DD3N
Active Standby Current
1144
1232
1320
mA
I DD4W
Operating Current: Burst Write
1980
2376
2684
mA
I DD4R
Operating Current: Burst Read
1980
2376
2860
mA
I DD5B
Burst Refresh Current
2772
2992
3212
mA
I DD6
Self-Refresh Current Normal Temperature Range (0-85C)
246
246
246
mA
I DD7
All Bank Interleave Read Current
3212
3784
4092
mA
Note: Module IDD was calculated from component IDD. It may differ from the actual measurement.
