M2S2G64CB(C)88G5N / M2S4G64CB(C)8HG5N

2GB: 256M x 64 / 4GB: 512M x 64

PC3(L)-10600 / PC3(L)-12800

Unbuffered DDR3(L) SO-DIMM

REV 1.0 2

05/2011

© NANYA TECHNOLOGY CORPORATION

NANYA reserves the right to change products and specifications without notice.

Ordering Information

Part Number

Speed

Organization

Power

Leads

Note

M2S2G64CC88G5N-CG

DDR3L-1333

PC3L-10600

667MHz (1.500ns @ CL = 9)

256Mx64

1.35V

Gold

M2S2G64CC88G5N-DI

DDR3L-1600

PC3L-12800

800MHz (1.250ns @ CL = 11)

M2S4G64CC8HG5N-CG

DDR3L-1333

PC3L-10600

667MHz (1.500ns @ CL = 9)

512Mx64

M2S4G64CC8HG5N-DI

DDR3L-1600

PC3L-12800

800MHz (1.250ns @ CL = 11)

M2S2G64CB88G5N-CG

DDR3-1333

PC3-10600

667MHz (1.500ns @ CL = 9)

256Mx64

1.5V

M2S2G64CB88G5N-DI

DDR3-1600

PC3-12800

800MHz (1.250ns @ CL = 11)

M2S4G64CB8HG5N-CG

DDR3-1333

PC3-10600

667MHz (1.500ns @ CL = 9)

512Mx64

M2S4G64CB8HG5N-DI

DDR3-1600

PC3-12800

800MHz (1.250ns @ CL = 11)

Pin Description

Pin Name

Description

Pin Name

Description

CK0, CK1

Clock Inputs, positive line

DQ0-DQ63

Data input/output

, 

Clock Inputs, negative line

DQS0-DQS7

Data strobes

CKE0, CKE1

Clock Enable

-

Data strobes complement



Row Address Strobe

DM0-DM7

Data Masks



Column Address Strobe



Temperature event pin



Write Enable



Reset pin

, 

Chip Selects

V

REFDQ

, V

REFCA

Input/output Reference

A0-A9, A11, A13-A15

Address Inputs

V

DDSPD

SPD and Temp sensor power

A10/AP

Address Input/Auto-Precharge

SA0, SA1

Serial Presence Detect Address Inputs

A12/

Address Input/Burst Chop

Vtt

Termination voltage

BA0-BA2

SDRAM Bank Address Inputs

V

SS

Ground

ODT0, ODT1

Active termination control lines

V

DD

Core and I/O power

SCL

Serial Presence Detect Clock Input

NC

No Connect

SDA

Serial Presence Detect Data input/output

Note: A14 is for 4GB modules only.
